OM Series Flowmeter - OM025A513-822R5

FLOMEC® OM Series Meters are an extremely versatile flowmeter which accurately measures high and low viscosity fluids. With no flow conditioning required and a small footprint, the OM025A513-822R5 flowmeter allows for compact installation. An accuracy of 0.5% and 0.03% repeatability regardless of viscosity changes make the OM Series a versatile meter. With a simple and reliable design concept using only two moving parts, they provide long service life and minimised maintenance costs. The OM025A513-822R5 flowmeter comes fitted with a FLOMEC® RT14 Rate Totaliser. The perfect display for users who require a more sophisticated local display which can also interface with external control or monitoring equipment. The RT14 features a backlit LCD, which provides optimal readability from a distance or in low-light conditions. Various output options are available to suit almost any flow measurement application, with a 4-20mA analogue signal for flowrate feedback and control, flow alarms for monitoring of critical processes, and a scaled pulse signal for remote monitoring of total volumes.
Product comes calibrated with standard calibration certificate.

Specifications

Series: OM Oval Gear

Model: 1"

Body Material: Aluminium Body

Rotor Material: Stainless steel Rotors with Carbon Ceramic Bearings

O-Ring Material: Teflon encapsulated viton O-Rings

Temperature Limits: 80°C

Process Connections: NPT female threaded

Cable Entries: 1/2" NPT

Integral Options: RT14 rate totaliser with GRN housing
